    A Step-by-Step Coding Tutorial on NVIDIA PhysicsNeMo: Darcy Flow, FNOs, PINNs, Surrogate Models, and Inference Benchmarking

    April 13, 2026
    Facebook Twitter Pinterest Telegram LinkedIn Tumblr WhatsApp Email
    A Step-by-Step Coding Tutorial on NVIDIA PhysicsNeMo: Darcy Flow, FNOs, PINNs, Surrogate Models, and Inference Benchmarking
    Share
    Facebook Twitter LinkedIn Pinterest Telegram Email
    kraken


    print(“\n” + “=”*80)
    print(“SECTION 4: DATA VISUALIZATION”)
    print(“=”*80)

    def visualize_darcy_samples(
    permeability: np.ndarray,
    pressure: np.ndarray,
    n_samples: int = 3
    ):
    “””Visualize Darcy flow samples.”””
    fig, axes = plt.subplots(n_samples, 2, figsize=(10, 4 * n_samples))

    for i in range(n_samples):
    im1 = axes[i, 0].imshow(permeability[i], cmap=’viridis’, origin=’lower’)
    axes[i, 0].set_title(f’Permeability Field (Sample {i+1})’)
    axes[i, 0].set_xlabel(‘x’)
    axes[i, 0].set_ylabel(‘y’)
    plt.colorbar(im1, ax=axes[i, 0], label=”k(x,y)”)

    im2 = axes[i, 1].imshow(pressure[i], cmap=’hot’, origin=’lower’)
    axes[i, 1].set_title(f’Pressure Field (Sample {i+1})’)
    axes[i, 1].set_xlabel(‘x’)
    axes[i, 1].set_ylabel(‘y’)
    plt.colorbar(im2, ax=axes[i, 1], label=”u(x,y)”)

    changelly

    plt.tight_layout()
    plt.savefig(‘darcy_samples.png’, dpi=150, bbox_inches=”tight”)
    plt.show()
    print(“✓ Saved visualization to ‘darcy_samples.png'”)

    visualize_darcy_samples(perm_train[:3], press_train[:3])

    print(“\n” + “=”*80)
    print(“SECTION 5: FOURIER NEURAL OPERATOR (FNO)”)
    print(“=”*80)

    “””
    The Fourier Neural Operator (FNO) learns mappings between function spaces
    by parameterizing the integral kernel in Fourier space.

    Key insight: Convolution in physical space = multiplication in Fourier space

    The FNO layer consists of:
    1. FFT to transform to frequency domain
    2. Multiplication with learnable weights (keeping only low-frequency modes)
    3. Inverse FFT to transform back
    4. Residual connection with a local linear transformation
    “””

    class SpectralConv2d(nn.Module):
    “””
    2D Spectral Convolution Layer for FNO.

    Performs convolution in Fourier space by:
    1. Computing FFT of input
    2. Multiplying with complex learnable weights
    3. Computing inverse FFT
    “””

    def __init__(
    self,
    in_channels: int,
    out_channels: int,
    modes1: int,
    modes2: int
    ):
    super().__init__()

    self.in_channels = in_channels
    self.out_channels = out_channels
    self.modes1 = modes1
    self.modes2 = modes2

    self.scale = 1 / (in_channels * out_channels)

    self.weights1 = nn.Parameter(
    self.scale * torch.rand(in_channels, out_channels, modes1, modes2, dtype=torch.cfloat)
    )
    self.weights2 = nn.Parameter(
    self.scale * torch.rand(in_channels, out_channels, modes1, modes2, dtype=torch.cfloat)
    )

    def compl_mul2d(self, input: torch.Tensor, weights: torch.Tensor) -> torch.Tensor:
    “””Complex multiplication for batch of 2D tensors.”””
    return torch.einsum(“bixy,ioxy->boxy”, input, weights)

    def forward(self, x: torch.Tensor) -> torch.Tensor:
    batch_size = x.shape[0]

    x_ft = torch.fft.rfft2(x)

    out_ft = torch.zeros(
    batch_size, self.out_channels, x.size(-2), x.size(-1) // 2 + 1,
    dtype=torch.cfloat, device=x.device
    )

    out_ft[:, :, :self.modes1, :self.modes2] = \
    self.compl_mul2d(x_ft[:, :, :self.modes1, :self.modes2], self.weights1)

    out_ft[:, :, -self.modes1:, :self.modes2] = \
    self.compl_mul2d(x_ft[:, :, -self.modes1:, :self.modes2], self.weights2)

    x = torch.fft.irfft2(out_ft, s=(x.size(-2), x.size(-1)))

    return x

    class FNOBlock(nn.Module):
    “””
    FNO Block combining spectral convolution with local linear transform.

    output = σ(SpectralConv(x) + LocalLinear(x))
    “””

    def __init__(
    self,
    channels: int,
    modes1: int,
    modes2: int,
    activation: str=”gelu”
    ):
    super().__init__()

    self.spectral_conv = SpectralConv2d(channels, channels, modes1, modes2)
    self.local_linear = nn.Conv2d(channels, channels, 1)

    self.activation = nn.GELU() if activation == ‘gelu’ else nn.ReLU()

    def forward(self, x: torch.Tensor) -> torch.Tensor:
    return self.activation(self.spectral_conv(x) + self.local_linear(x))

    class FourierNeuralOperator2D(nn.Module):
    “””
    Complete 2D Fourier Neural Operator for learning operators.

    Architecture:
    1. Lift input to higher dimensional channel space
    2. Apply multiple FNO blocks (spectral convolutions + residuals)
    3. Project back to output space

    This learns the mapping: k(x,y) -> u(x,y) for Darcy flow
    “””

    def __init__(
    self,
    in_channels: int = 1,
    out_channels: int = 1,
    modes1: int = 12,
    modes2: int = 12,
    width: int = 32,
    n_layers: int = 4,
    padding: int = 9
    ):
    super().__init__()

    self.modes1 = modes1
    self.modes2 = modes2
    self.width = width
    self.padding = padding

    self.fc0 = nn.Linear(in_channels + 2, width)

    self.fno_blocks = nn.ModuleList([
    FNOBlock(width, modes1, modes2) for _ in range(n_layers)
    ])

    self.fc1 = nn.Linear(width, 128)
    self.fc2 = nn.Linear(128, out_channels)

    def get_grid(self, shape: Tuple, device: torch.device) -> torch.Tensor:
    “””Create normalized grid coordinates.”””
    batch_size, size_x, size_y = shape[0], shape[2], shape[3]

    gridx = torch.linspace(0, 1, size_x, device=device)
    gridy = torch.linspace(0, 1, size_y, device=device)
    gridx, gridy = torch.meshgrid(gridx, gridy, indexing=’ij’)

    grid = torch.stack([gridx, gridy], dim=-1)
    grid = grid.unsqueeze(0).repeat(batch_size, 1, 1, 1)

    return grid

    def forward(self, x: torch.Tensor) -> torch.Tensor:
    batch_size = x.shape[0]

    grid = self.get_grid(x.shape, x.device)

    x = x.permute(0, 2, 3, 1)
    x = torch.cat([x, grid], dim=-1)

    x = self.fc0(x)
    x = x.permute(0, 3, 1, 2)

    if self.padding > 0:
    x = F.pad(x, [0, self.padding, 0, self.padding])

    for block in self.fno_blocks:
    x = block(x)

    if self.padding > 0:
    x = x[…, :-self.padding, :-self.padding]

    x = x.permute(0, 2, 3, 1)
    x = F.gelu(self.fc1(x))
    x = self.fc2(x)
    x = x.permute(0, 3, 1, 2)

    return x

    print(“\nCreating Fourier Neural Operator model…”)
    fno_model = FourierNeuralOperator2D(
    in_channels=1,
    out_channels=1,
    modes1=8,
    modes2=8,
    width=32,
    n_layers=4,
    padding=5
    ).to(device)

    n_params = sum(p.numel() for p in fno_model.parameters() if p.requires_grad)
    print(f”✓ FNO Model created with {n_params:,} trainable parameters”)
